Armstrong Siddeley Saphire Mk1 1954 high torque starter motor

LMS1450

Type Weight Voltage Polarity Power
Denso OSGR *r 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 9 29mm
Armstrong Siddeley Star Sapphire 50A Dynator

LMDC45-RD-TwinV

Amp Voltage Polarity B+ Position Pulley
50A 12V -VE Fixed LMP023
Armstrong Siddeley Star Sapphire 50A Dynator (+VE Ground)

LMDC45-RD-TwinV+VE

Amp Voltage Polarity B+ Position Pulley
50A 12V -VE Fixed LMP023
ARO 10 | Audi A3 | Ford Galaxy | Skoda Octavia | Seat & VW 'Various' high torque starter motor

LMS236

Type Weight Voltage Polarity Power
Denso OSGR *r 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CCW 11 29mm
ARO 10 | Audi A3 | Ford Galaxy | Skoda Octavia | Seat & VW 'Various' Super-duty starter motor

LMS236-2.0

Type Weight Voltage Polarity Power
Denso OSGR 4.1Kg / 9.03lbs 12V Both 2.0kW
Rotation Rotation Rotation
CCW 11 29mm
Arrows A13 '92-'93 Off Car Starter | Remote Starter (19:1 reduction ratio)

LMS5028-7.8-CCW-A13

Type Voltage Polarity Power Rotation
Denso PLGR 24V Both 7.8kW CCW
Aston Martin | Chrysler | Hemi | Mopar V8 (rotatable RH) super-duty starter motor

LMS1412-10

Type Weight Voltage Polarity Power
Denso OSGR 4.1Kg / 9.03lbs 12V Both 2.0kW
Rotation Rotation Rotation
CW 10 32mm
Aston Martin | Chrysler | Hemi | Mopar V8 (rotatable) high torque starter motor

LMS568

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 32mm
Aston Martin | Chrysler | Hemi | Mopar V8 (rotatable) super-duty starter motor

LMS569

Type Weight Voltage Polarity Power
Denso OSGR 4.1Kg / 9.03lbs 12V Both 2.0kW
Rotation Rotation Rotation
CW 10 32mm
Aston Martin | Chrysler | Hemi | Mopar V8 (short drive) high torque starter motor

LMS924

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 32mm
Aston Martin | Chrysler | Hemi | Mopar V8 high torque starter motor

LMS012

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 32mm
Aston Martin 1.5L 'international' 50A Dynator

LMDAM004

Amp Voltage Polarity B+ Position Pulley
50A 12V -VE Fixed Uses Original
Aston Martin 15|98 50A Dynator

LMDAM002

Amp Voltage Polarity B+ Position Pulley
50A 12V -VE Fixed Uses Original
Aston Martin AMR1 170A Alternator

LMA533-HO

Amp Hand Lugs Type Weight
170A R/H 2 Billet 3.9Kg / 8.61lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP083-15
Aston Martin AMR1 95A Alternator

LMA533

Amp Hand Lugs Type Weight
95A R/H 2 Billet 3.9Kg / 8.61lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP083-15
Aston Martin AMR1 Group C high torque starter motor

LMS762

Type Voltage Polarity Power
Hitachi WFGR 12V Both 2.5kW
Aston Martin DB2 high torque starter motor

LMS426

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 40mm
Aston Martin DB2-DB4 70A Dynator

LMDC45-70-AM

Amp Hand Lugs Type Weight
70A RH 3 Denso 3.9Kg / 8.61lbs
Voltage Polarity Connection B+ Position Pulley
12V -VE B+ / Lamp Fixed LMP061
Aston Martin DB2-DB4 70A Dynator (+VE Ground)

LMDC45-70-AM+VE

Amp Hand Lugs Type Weight
70A RH 3 Denso 3.9Kg / 8.61lbs
Voltage Polarity Connection B+ Position Pulley
12V +VE B+ / Lamp Fixed LMP061
Aston Martin DB3, DB4, DB5 & DB6 (left hand) (motor on top) high torque starter motor

LMS016

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 40mm
Aston Martin DB3, DB4, DB5 & DB6 (right hand) (motor underneath) high torque starter motor

LMS1521

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 40mm
Aston Martin DB3-6 (DBS transmission & bellhousing) high torque starter motor

LMS678

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 40mm
Aston Martin DB7 (6 cylinder) high torque starter motor

LMS067

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 9 29mm
Aston Martin DB9 | One-77 | Rapide | Vanquish | Virage 180A Alternator

LMA669-LO

Amp Hand Lugs Type Weight
180A 3-Lug PAD 3 Cast 6.9Kg / 15.21lbs
Voltage Polarity Connection Pulley
12V -VE B+ / BVS / RC / LI LMCP009
Aston Martin DB9 | One-77 | Rapide | Vanquish | Virage 240A Alternator

LMA669

Amp Hand Lugs Type Weight
240A 3-Lug PAD 3 Cast 6.9Kg / 15.21lbs
Voltage Polarity Connection Pulley
12V -VE B+ / BVS / RC / LI LMCP009
Aston Martin DB9 | One-77 | Rapide | Vanquish | Virage 290A Alternator

LMA669-MHO

Amp Hand Lugs Type Weight
290A 3-Lug PAD 3 Cast 6.9Kg / 15.21lbs
Voltage Polarity Connection Pulley
12V -VE B+ / BVS / RC / LI LMCP009
Aston Martin DB9 | One-77 | Rapide | Vanquish | Virage 390A Alternator

LMA669-HO

Amp Hand Lugs Type Weight
390A 3-Lug PAD 3 Cast 6.9Kg / 15.21lbs
Voltage Polarity Connection Pulley
12V -VE B+ / BVS / RC / LI LMCP009
Aston Martin DBR1 high torque starter motor

LMS146

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CCW 13 40mm
Aston Martin MKII 'Early' 50A Dynator

LMDAM001

Amp Voltage Polarity B+ Position Pulley
50A 12V -VE Fixed Includes Drive
Aston Martin MKII 'Late' 50A Dynator

LMDAM003

Amp Voltage Polarity B+ Position Pulley
50A 12V -VE Fixed Uses Original
Aston Martin One-77 OE starter motor

LMS288

Type Weight Voltage Polarity Power
Denso OSGR 4.1Kg / 9.03lbs 12V Both 2.0kW
Rotation Rotation Rotation
CW 15 45mm
Aston Martin Pre - War 1.5L high torque starter motor

LMS275

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 37mm
Aston Martin Pre - War 2.0L Speed high torque starter motor

LMS274

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 9 33mm
Aston Martin Pre - War 2L 15|98 high torque starter motor

LMS276

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 9 35mm
Aston Martin Pre-War 1.5L 'international' high torque starter motor

LMS488

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 10 37mm
Aston Martin V12 (DB7 | DB9 | Vanquish) high torque starter motor

LMS068

Type Weight Voltage Polarity Power
Denso OSGR 3.7Kg / 8.15lbs 12V Both 1.4kW
Rotation Rotation Rotation
CW 9 29mm
Aston Martin V8 & Rolls Royce 120A Alternator (10V)

LMA475-LO-10V

Amp Hand Lugs Type Weight
120A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP001
Aston Martin V8 & Rolls Royce 120A Alternator (13V)

LMA475-LO-13V

Amp Hand Lugs Type Weight
120A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP124
Aston Martin V8 & Rolls Royce 120A Alternator (17V)

LMA475-LO-17V

Amp Hand Lugs Type Weight
120A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP244-17
Aston Martin V8 & Rolls Royce 175A Alternator (10V)

LMA475-10V

Amp Hand Lugs Type Weight
175A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP001
Aston Martin V8 & Rolls Royce 175A Alternator (13V)

LMA475-13V

Amp Hand Lugs Type Weight
175A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP124
Aston Martin V8 & Rolls Royce 175A Alternator (17V)

LMA475-17V

Amp Hand Lugs Type Weight
175A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP244-17
Aston Martin V8 & Rolls Royce 250A Alternator (10V)

LMA475-MHO-10V

Amp Hand Lugs Type Weight
250A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP001
Aston Martin V8 & Rolls Royce 250A Alternator (13V)

LMA475-MHO-13V

Amp Hand Lugs Type Weight
250A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP124
Aston Martin V8 & Rolls Royce 250A Alternator (17V)

LMA475-MHO-17V

Amp Hand Lugs Type Weight
250A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP244-17
Aston Martin V8 & Rolls Royce 320A Alternator (10V)

LMA475-HO-10V

Amp Hand Lugs Type Weight
320A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP001
Aston Martin V8 & Rolls Royce 320A Alternator (13V)

LMA475-HO-13V

Amp Hand Lugs Type Weight
320A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP124
Aston Martin V8 & Rolls Royce 320A Alternator (17V)

LMA475-HO-17V

Amp Hand Lugs Type Weight
320A 180° 2 Cast 5.3Kg / 11.71lbs
Voltage Polarity Connection Pulley
12V -VE B+ / Lamp LMP244-17
Aston Martin V8 105A Alternator

LMA063

Amp Hand Lugs Type Weight
105A 180° 2 Cast 6.4Kg / 14.11lbs
Voltage Polarity Connection B+ Position Pulley
12V -VE B+ / S / L Fixed LMP067
Aston Martin V8 'Efi' 120A Alternator

LMA010

Amp Hand Lugs Type Weight
120A 180° 2 Cast 6.4Kg / 14.11lbs
Voltage Polarity Connection B+ Position Pulley
12V -VE B+ / P / L / F / S Fixed LMP214-17

Type	Weight	Voltage	Polarity	Power
Denso OSGR *r	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	9	29mm

Amp	Voltage	Polarity	B+ Position	Pulley
50A	12V	-VE	Fixed	LMP023

Amp	Voltage	Polarity	B+ Position	Pulley
50A	12V	-VE	Fixed	LMP023

Type	Weight	Voltage	Polarity	Power
Denso OSGR *r	3.7Kg / 8.15lbs	12V	Both	1.4kW
CCW	11	29mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	4.1Kg / 9.03lbs	12V	Both	2.0kW
CCW	11	29mm

Type	Voltage	Polarity	Power	Rotation
Denso PLGR	24V	Both	7.8kW	CCW

Type	Weight	Voltage	Polarity	Power
Denso OSGR	4.1Kg / 9.03lbs	12V	Both	2.0kW
CW	10	32mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	32mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	4.1Kg / 9.03lbs	12V	Both	2.0kW
CW	10	32mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	32mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	32mm

Amp	Voltage	Polarity	B+ Position	Pulley
50A	12V	-VE	Fixed	Uses Original

Amp	Voltage	Polarity	B+ Position	Pulley
50A	12V	-VE	Fixed	Uses Original

Amp	Hand	Lugs	Type	Weight
170A	R/H	2	Billet	3.9Kg / 8.61lbs
12V	-VE	B+ / Lamp	LMP083-15

Amp	Hand	Lugs	Type	Weight
95A	R/H	2	Billet	3.9Kg / 8.61lbs
12V	-VE	B+ / Lamp	LMP083-15

Type	Voltage	Polarity	Power
Hitachi WFGR	12V	Both	2.5kW

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	40mm

Amp	Hand	Lugs	Type	Weight
70A	RH	3	Denso	3.9Kg / 8.61lbs
12V	-VE	B+ / Lamp	Fixed	LMP061

Amp	Hand	Lugs	Type	Weight
70A	RH	3	Denso	3.9Kg / 8.61lbs
12V	+VE	B+ / Lamp	Fixed	LMP061

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	40mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	40mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	40mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	9	29mm

Amp	Hand	Lugs	Type	Weight
180A	3-Lug PAD	3	Cast	6.9Kg / 15.21lbs
12V	-VE	B+ / BVS / RC / LI	LMCP009

Amp	Hand	Lugs	Type	Weight
240A	3-Lug PAD	3	Cast	6.9Kg / 15.21lbs
12V	-VE	B+ / BVS / RC / LI	LMCP009

Amp	Hand	Lugs	Type	Weight
290A	3-Lug PAD	3	Cast	6.9Kg / 15.21lbs
12V	-VE	B+ / BVS / RC / LI	LMCP009

Amp	Hand	Lugs	Type	Weight
390A	3-Lug PAD	3	Cast	6.9Kg / 15.21lbs
12V	-VE	B+ / BVS / RC / LI	LMCP009

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CCW	13	40mm

Amp	Voltage	Polarity	B+ Position	Pulley
50A	12V	-VE	Fixed	Includes Drive

Amp	Voltage	Polarity	B+ Position	Pulley
50A	12V	-VE	Fixed	Uses Original

Type	Weight	Voltage	Polarity	Power
Denso OSGR	4.1Kg / 9.03lbs	12V	Both	2.0kW
CW	15	45mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	37mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	9	33mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	9	35mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	10	37mm

Type	Weight	Voltage	Polarity	Power
Denso OSGR	3.7Kg / 8.15lbs	12V	Both	1.4kW
CW	9	29mm

Amp	Hand	Lugs	Type	Weight
120A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP001

Amp	Hand	Lugs	Type	Weight
120A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP124

Amp	Hand	Lugs	Type	Weight
120A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP244-17

Amp	Hand	Lugs	Type	Weight
175A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP001

Amp	Hand	Lugs	Type	Weight
175A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP124

Amp	Hand	Lugs	Type	Weight
175A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP244-17

Amp	Hand	Lugs	Type	Weight
250A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP001

Amp	Hand	Lugs	Type	Weight
250A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP124

Amp	Hand	Lugs	Type	Weight
250A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP244-17

Amp	Hand	Lugs	Type	Weight
320A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP001

Amp	Hand	Lugs	Type	Weight
320A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP124

Amp	Hand	Lugs	Type	Weight
320A	180°	2	Cast	5.3Kg / 11.71lbs
12V	-VE	B+ / Lamp	LMP244-17

Amp	Hand	Lugs	Type	Weight
105A	180°	2	Cast	6.4Kg / 14.11lbs
12V	-VE	B+ / S / L	Fixed	LMP067

Amp	Hand	Lugs	Type	Weight
120A	180°	2	Cast	6.4Kg / 14.11lbs
12V	-VE	B+ / P / L / F / S	Fixed	LMP214-17

Engineered Solutions to Real Problems●OE Quality, No Compromise

Alternators

High output, low rpm, superior reliability, application specific 'fit and forget' direct replacement OE units.

More info

Dynators

Alternators disguised as dynamos. Authentic and reliable: the perfect upgrade.

More info

Starter Motors

Bespoke, OE quality, high torque, gear reduction and durable. Ideal for hostile environments, or the ultimate upgrade.

More info

Spares

WOSP manufacture and stock a complete range of spares including pulleys, brackets, kits, tensioners, pinions, regulators and looms.

More info

Spares

PRODUCT FILTER

PRODUCT CATEGORY

Engineered Solutions to Real Problems●OE Quality, No Compromise

Alternators

Dynators

Starter Motors

Spares
